🔷Product Drawing

🔷Basic Performance Spec

🔷Performance Curve

🔷Product Overview

Micro Peltiers are small thermoelectric cooling modules that use the Peltier effect to achieve thermoelectric cooling.

Unlike traditional compressor-based cooling methods, Micro Peltiers have no mechanical moving parts such as compressors or refrigerants. When powered on, a temperature difference is created across the two sides of the module: one side absorbs heat to form the cold side, while the other side releases heat to form the hot side.

Due to their small size, compact structure, fast response speed, lack of mechanical moving parts, and ease of temperature control, they are suitable for small electronic devices, precision instruments, and applications requiring localized temperature control.

As a Thermoelectric Cooling Module supplier, we can provide standard and customized Micro Peltier solutions for different applications, and support OEM, ODM, and bulk purchasing.

🔷Product Features

1. Compact Design

Micro Peltiers are small in size, making them suitable for devices with limited installation space.

2. Precise Temperature Control

By adjusting the operating current, the cooling effect can be controlled, making them suitable for devices that require temperature regulation.

3. Fast Thermal Response

Thermoelectric cooling modules generate a thermoelectric effect immediately after being powered on, making them suitable for scenarios that require rapid temperature changes.

4. No Mechanical Moving Parts

The modules contain no mechanical moving structures such as compressors, which facilitates compact design for small devices.

5. Customizable

Customization is available for dimensions, voltage, current, wires, connectors, and other aspects according to customer requirements.

6. OEM & ODM Support

Suitable for equipment manufacturers, wholesalers, engineering projects, and long-term bulk purchasing customers.

🔷Product Applications

Micro Peltiers are suitable for a wide range of small devices and precision temperature control applications, such as:

For industrial equipment, laser equipment, semiconductor equipment, and electronic product manufacturers, the appropriate thermoelectric cooling module can be selected according to the specific application.

🔷Product Structure

🔷Operation Principle / Work Principle

The working principle of Micro Peltiers is based on the Peltier Effect.

When a direct current passes through a thermocouple made of different semiconductor materials, heat is transferred from one side of the module to the other.

Therefore:

Cold Side → Absorbs Heat

Hot Side → Releases Heat

In simple terms:

Power on → Cold side absorbs heat → Hot side releases heat → Temperature difference is formed → Cooling is achieved

By changing the direction of the current, the direction of heat transfer can also be changed, enabling the same thermoelectric module to have bidirectional temperature control capability for both heating and cooling.

In actual use, the heat dissipation capability of the hot side directly affects the cooling performance of the cold side. Therefore, in Micro Peltier applications, heat sinks, fans, water cooling structures, or other heat dissipation solutions are usually required.

🔷FAQ

Q1: What are Micro Peltiers?

Micro Peltiers are compact thermoelectric cooling modules that use the Peltier effect to transfer heat from one side to the other for cooling and temperature control.

Q2: Can you provide custom thermoelectric cooling modules?

Yes. We provide custom thermoelectric cooling module solutions, including dimensions, voltage, current, wires and connectors according to customer requirements.

Q3: Do you support OEM and ODM?

Yes. OEM and ODM services are available for equipment manufacturers and project customers.

Q4: Are you a thermoelectric cooling module manufacturer and supplier?

Yes. We provide thermoelectric cooling modules for industrial, electronic, optical, medical and temperature-control applications.

Q5: Can I buy thermoelectric cooling modules in bulk?

Yes. Bulk thermoelectric cooling module supply is available for distributors, equipment manufacturers and long-term projects.

Q6: Do you provide samples before mass production?

Sample orders can be arranged for customers who need to verify module dimensions and performance before mass production.

Q7: Can the wire and connector be customized?

Yes. Wire length, wire specification and connector type can be customized according to the customer's equipment requirements.

Q8: What applications are Micro Peltiers suitable for?

They can be used for laser cooling, optical equipment, semiconductor temperature control, medical equipment, electronic devices, miniature refrigeration and other precision temperature-control applications.

Q9: Do you provide China thermoelectric cooling module supply?

Yes. We can provide China thermoelectric cooling module supplier and manufacturing support for overseas customers, including OEM, ODM and bulk orders.

Q10: How do I select the right Micro Peltier?

The selection should consider module size, voltage, current, cooling capacity, ΔTmax, hot-side temperature, cold-side target temperature and heat dissipation conditions. Providing these parameters helps determine a suitable model.
